📌LAB POINTS

• vinyl noise reduction system detects and reduces vinyl crackle via algorithmic noise reduction system (NRS)
• connect between your phono preamp and amplifier / power speakers
• the unit will automatically activate when signal is detected unless bypassed
• (2) de-crackling intensity algorithms, can be fine-tuned via front panel knob
• instant feedback via front panel LED
• 24-bit DSP / 96 kHz sampling rate for precise processing
• line-level operation
• full aluminum housing
• available in silver or black

"Connect the output of your phono preamplifier to the Vinyl NRS Box S3. First, the line signal gets digitized with a bit depth of 24-bits and a sampling rate of 96 kHz. If the input is too loud, the overflow LED will show it to you. You can then activate the -6 dB switch and the gain is fine now. Crackling parts can be reduced by up to 8 dB which is a big improvement for the listening experience. You can easily adjust the sensitivity with the potentiometer on the front. If you don‘t want to use the De-Crackling function, just turn the potentiometer completely to the left and the algorithm is in bypass." - Pro-Ject

🔎TECH SPECS

• Internal sampling: 96 kHz/24 bits
• Internal processing: 56-bit accumulator, double precision
• Frequency response 20Hz to 20 kHz: -0,6 dB / +0,1dB
• Frequency response 30Hz to 20 kHz: -0,2 dB / +0,1dB
• Clip indication: -0,6 dB below real clipping
• Bypass mode: galvanic linked together (Rlink<0,3 ohm)
• THD: <0,009% (500 mVrms Input Level)
• VNRS noise/rumble reduce: up to 8dB (20Hz to 20 kHz)
• De-Click reduce (basic): 8 dB (3kHz to 20 kHz)
• De-Click reduce (intensity): 12 dB (2kHz to 20 kHz)
• Outboard power supply: 18V/500mA DC, suitable for your country's mains
• supply
• Power consumption in standby: 0W OFF/Standby, 2.2W ON (without outboard power supply)
• Dimensions: WxHxD: 4" x 1.5" x 4" / 103 x 37 x 104 mm
• Weight: 0.75 lbs / 340 g

📦COMES WITH

• power supply
